Alpha HT HEPA Filters
This high temperature HEPA filter is available in both gasket and fluid seal options.
Typical Applications – Microelectronics | Pharmaceutical
Description
Alpha HT HEPA Filters
HIGH TEMPERATURE HEPA FILTERS
Product Overview
- Stainless steel frame with separator-style microglass media pack
- For applications with requirements up to 1000°F (540°C) (exhaust air only) or 500°F (260°C) (supply air)
- Gasket or fluid seal available (fluid seal has maximum service temperature of 390°F (199°C)
- Individually tested for certified performance, scan testing available (on 500° only)
Typical Applications – Microelectronics | Pharmaceutical
AAF Flanders manufactures metal-frame separator-style HEPA filters for applications with high-temperature requirements up to 1,000°F (540°C) for exhaust air only and 500°F (260°C) for supply air. High temperature filters are available with either a gasket or fluid seal. Filters with BluJel® Fluid Seal have a maximum service temperature of 390°F (199°C).
HEPA Filters
Each HEPA filter has a minimum efficiency of 99.97% on 0.30 micrometer size particles when tested at rated capacity on a Q-107 Penetrometer. Each filter is challenged with an approved nearly monodispersed oil aerosol of 0.30 micrometer size. By measuring the upstream and downstream concentration of these particles with a light scattering photometer, the penetration can be determined and the efficiency can be calculated.
Scan Tested HEPA Filters
Each scan tested HEPA filter has a minimum efficiency of 99.99% on 0.30 micrometer particles. Scan testing is in accordance with Section 6.2 of IEST-RP-CC034.1, HEPA and ULPA Filters Leak Tests. In the scan test, the filter is challenged with a high concentration of an approved oil aerosol or PSL (Polystyrene Latex Spheres). The media pack and pack-to-frame seal is scanned using a photometer or particle counter to ensure that there are no leaks greater than .01% of the upstream concentration at 100 FPM face velocity. Scan testing is only available for the 500°F (260° C) model.
Efficiency
HEPA
Filter Depth
12"
Media Type
Fiberglass
Frame Material
Stainless Steel
Max Operating Temperature
1,000˚F (540˚C) | 500˚F (260˚C)
