Single Phase Induction Motors 240V
Monarch Single Phase Motors 240V
- Wide range of low voltage options ranging 0.18kW to 3kW
- Alloy Frame motor with top mounted terminal box
- Class F insulation with a Class B temperature rise
- Capacitor start, capacitor run for good starting torque
Description
Monarch Single Phase Induction Motors from TECO are a range of high quality, Totally Enclosed Fan Cooled (IC411), squirrel cage induction motors, designed, manufactured and tested to the latest International and Australian Standards. Metric frame motors to AS1359.
Motors less 1.5kW are 240 Volts Single Phase 50 Hz and include manual overload protection.
Motors 1.5kW and larger are 240/480 Volts Single Phase 50 Hz.
Ambient
Designed to operate in ambient conditions of -15°C to +40°C as standard.
Altitude
Designed for operation at an altitude up to 1000 metres above sea level.
Balance
Rotors are dynamically balanced with a half key to Class N, according to AS1359.50
Electric Supply
Designed for 230-250 Volt single phase 50 Hz. Motors 1.5kW and larger are dual voltage 240/480 Volts.
Finish
High corrosion protected surface with two finish coats of gloss acrylic resin in finish colour Teal T63 to AS2700. All castings are mechanically cleaned and degreased with aluminium components being primed externally.
Stator and windings
High grade insulated cold rolled electro magnetic steel laminations. Vacuum impregnated Class F insulation with design temperature rise of class B for long motor life and thermal reserve for abnormal conditions.
Bearing and Lubrication System
Motors have a ball/ball bearing combination and are fitted with greased for life sealed bearings. Shaft Oil seals are provided at each end on all motors to exclude the ingress of dust and water.
Winding Protection
Manual Reset Thermal Overload device are fitted to motors up to an including 1.1 kW to protect against overload conditions.
Data sheets and manuals
Frame sizes
63 to 100L
Performance requirements
meets AS1359
Protection rating
IP55
Duty rating
maximum continuously rated type S1
Mounting
available Foot, Foot and flange (C and D types), Flange (C and D types)
Standards
designed and manufactured to IEC34, IEC72, AS1359 with Quality Assurance to ISO9001. Motors are CE marked.
