DriPak®NX Bag Filter
The DriPak NX pocket filter is the best performing A+ label filter in the industry
Highest dust holding capacity
Nanowave® tapered pockets
Fully incinerable
Applications include – Automotive | Commercial Buildings | Data Centers | Food and Beverage | Hospitality | Industrial | Museums & Historic Storage | Schools and Universities
Description
DriPak®NX Bag Filter
Product Overview
- Proprietary AAF Flanders design with stable Nanowave® tapered pockets for optimum airflow
- Highest dust holding capacity (DHC) for extra-long filter life
- Next generation media eliminates need for prefiltration, drastically reducing overall operating costs
- Sturdy and lightweight injection molded polyurethane (PU) header for easy handling and maintenance
- Pockets are encapsulated during the header molding process to form a perfect seal between filter media and header
- Innovative construction eliminates the leakage potential found with mechanically fastened pockets
- Synthetic media with mechanical efficiency—ASHRAE 52.2 Appendix J certified performance
- Fully incinerable for minimized environmental impact
- Available in MERV 15/15A and MERV 13/13A efficiencies
Typical Applications include – Automotive | Commercial Buildings | Data Centers | Food and Beverage | Hospitality | Industrial | Museums & Historic Storage | Schools and Universities
Designed and engineered by AAF Flanders, the DriPak® NX pocket filters offer industry leading functionality and performance. It is the best choice for saving both time and money, while improving indoor air quality. With the lowest Total Cost of Ownership of all mechanical efficiency pocket filters, the DriPak NX filter will help protect your environment, reduce your business risk, and optimize your clean air spending.
The DriPak NX filter provides best-in-class performance for energy efficiency and ease of installation based on a unique combination of high-tech filter material, pocket design, and ergonomic header construction. The filter can be used for a wide variety of applications, ranging from final filtration for office buildings to prefiltration for critical cleanroom processes. The DriPak NX filter combines high indoor air quality, environmental savings, and low operating costs for less labor, less energy, and more performance.
Improved Process Performance
The DriPak NX filter offers uncompromised performance with a combination of highly efficient synthetic media and an injection molded PU header for an airtight seal. The sturdy header configuration and stable tapered pockets optimize airflow for improved indoor conditions and easier filter handling and maintenance.
Environmental Savings
Based on its proprietary pocket design, with an optimized geometry for each individual filter configuration, the DriPak NX has proven to be extremely energy-efficient. DriPak NX is the best performing filter in the industry.. With the injection molded polyurethane header, the air filter is also fully incinerable, whereas its optimized dust holding capacity gives a long service life.
Beneficial Total Cost of Ownership
Research has shown that, when upgrading an existing air filtration system with more efficient filters, the financial benefits exceed the initial costs of the more efficient filters. The DriPak filters are ideal for upgrading existing installations to achieve better indoor air quality and performance. Combined with the extremely low energy consumption and highest ease of maintenance, use of this filter results in lower lifecycle costs and total cost of ownership.
Media Type
Synthetic
Max Operating Temperature
158˚F (70˚C)
Special Size Available
No
Frame Material
Polyurethane Galvanized Steel Beechwood Plastic
