Ceiling Fan AC
Azure
Maximum Airflow 11,542m³/hr
No Light | E27 Light | LED Light
Value for money
Suitable for Smaller Bedrooms, Studies and Home Offices
| 20333 |
Description
The 1220mm (48″) diameter Azure is an excellent choice for decorating on a budget or for use in smaller rooms.
Featuring high airflow for its compact size the Azure reflects a commitment to quality and reliability.
The Azure takes value for money to the next level.
Ceiling fans circulate air within a room and provide a cooling effect through the action of air moving over the skin.
In addition to making the room feel up to 6° cooler, they can significantly assist in savings up to 30% off your energy bills.
In winter ceiling fans redistribute warm air that gathers at the ceiling.
Running your fans in reverse, draws the air that naturally rises and gently re-circulating it throughout the room. Therefore balance the room’s temperature.
All ceiling fans should be at least 2.1 meters from floor to tip of the blades and at least 300mm from ceiling.
AC vs DC FANS
Alternating Current Motors (AC) use supplied power directly and regulate speeds by controlling frequency. AC Motors generally only have 3 speeds.
Direct Current motors (DC) convert supplied power directly. and regulate speeds by controlling electrical current. These Motors use up to 70% less energy than standard AC fans. Furthermore DC Ceiling Fans are more efficient, offering virtually silent operation.
Direct Current models usually have 5 or 6 speeds and are remote controlled.
Ceiling Fans purchased through Davis + Spence are covered by a Manufacturer’s Warranty
Always use a licenced professional for installation.
| 20333 |
•
Safe, quiet 48" New Zealand Timber Blades
•
3 Speed wall control
•
Suitable for Indoor Use Only
•
2 year in home warranty (further 3 year replacement warranty)
•
E27 Light option
•
CCT LED Light Kit & Dimmable
Instruction Manual
Motor
16 Pole, 153mm x 15mm motor Made with the highest grade copper windings and silicone steel stator. Bearings are sealed to ensure quiet operation and long life.
Motor Housing
Materials: Pressed Steel
Available Motor Housing Colours
White, Brushed Chrome
Blades
1220mm (48”) Straight Style Materials: NZ plywood, Painted finish Blade Pitch: 12°
Available Blade Colours
White, Brushed Silver
Extra Information
3 Speed wall controller | Reversible
Standard Canopy Cover
Suitable for flat and pitched ceilings up to 32°
Wall Controller Speed Capacitor Values
3.5µF & 2µF
Rotational Diameter
1220mm (48”) Blade Sweep
Accessories (Supplied separately)
Remote Control Extension Down Rod 21mm diameter (wire harness included) | T-Hook for ceiling roses
Warranty
1 year standard warranty “in home” on electronic parts | 2 years standard warranty “in home” on mechanical parts (including motors) | 3 years extended warranty on motor only (excluding labour)
Available integrated light option 1
Twin E27 screw sockets (bulbs not supplied)
Available integrated light option 2
18W CCT LED 3000K, 4000K or 6000K
